Description
Greenlee 6906 Description
- 2-Speed motor that delivers the fastest pulling time for all pulling needs over the widest (10,000 lbs.) range
- Strong, rugged motor designed specifically for both big and small cable pulling applications up to 10,000 lbs.
- Easy control features for increased productivity
- On-board force gauge provides visual communicationof pulling force and speed changes
- Quick speed change from highspeed to low-speed by simplydouble tapping foot pedal
- Removable foot pedal for convenience
Greenlee 6906 Includes
- (1) UT10-2S Puller assembly
- (1) MBV Mobile VersiBoom II
- (1) 00560 4’ boom
- (1) 00561 3’ boom
- (2) 00562 Elbow/Hose Assembly
- (1) 00564 2-1/2” adaptor
- (1) 00565 3” adaptor
- (1) 00567 Short hanger
- (1) 00589 Long hanger
Mobile VersiBoom™ Features
- Sets up in less than 2 minutes
- Versatility to set up
- Easy to store and transport
Greenlee 6906 Specifications
| CONTINUOUS OPERATION: | 0 lbs. to 6,500 lbs. (0 kN to 28.9 kN) |
| 15 MINUTES ON / 15 MINUTES OFF: | 6,500 lbs. to 8,000 lbs. (28.9 kN to 35.6 kN) |
| MOMENTARY | 8,000 lbs. to 10,000 lbs. (35.6 kN to 44.5 kN) |
| No Load: | High Speed - 16 ft/min (4.88 m/min) |
| 2,000 lbs. (8,900 N): | High Speed - 14 ft/min (4.27 m/min) |
| 4,000 lbs. (17.8 kN): | High Speed - 12 ft/min (3.66 m/min) |
| 6,000 lbs. (26.7 kN): | Low Speed - 7 ft/min (2.13 m/min) |
| 8,000 lbs. (35.6 kN): | Low Speed - 6 ft/min (1.83 m/min) |
